High Tek USA
VFFS Bagger Scale Combo Unit
- World class standard, perfect performance
- Installed with safety door to ensure protection to operator
- PLC control with 7" colorful fast feedback touch screen
- Modular frame and remote electric box for easy maintenance
- Servo motor driven dual belt film pulling system
- Fiber optics sensor for accurate eye-mark tracking
- Constant heat sealing by PID temperature controller
- Self-diagnose and error indication system
- Film-end alarm and stop
- Perfect synchronization with dosing machine, date printer, counter and reclose bag zipper device, etc
- This machine can be customized to make gusset bag, 3-side, 4-side seal bag, stand-up and triangle bag
What It's Used For
- Various dosing system available.
- Granule: volumetric cup filler, multi-head combination scale.
- Powder: auger screw filler.
- Liquid, paste: piston pump filler, magnetic pump filler, rotor pump filler.
- Vibration counting device
- Packed with heat sealable laminates film
Combo Unit Features
- Available in 10 or 14 Heads
- 0.5 Liter Hopper Size
- Dimpled or Flat Metal Available
See It In Action
Options Available
- Nitrogen Flush Available
- Hole Punch Available
- Tear Notch Available
- Standard Pillowbag
- Three Sided or Four Sided Seal
- Flat Bottom Gusset
- Stick Packs
- Zipper Bag
VFFS Bagger
Vertical Form Fill Seal Machines
- Control System: Programmable PLC base
- HMI: 7" Color Touch Screen
- Seal Jaws: Servo Motor or Pneumatic
- Machine Size (LxWxH): 1457mm X 1110mm X 1828mm
- Max Speed: 130 Bags Per Minute
- Average Bag Size: 340mm X 210mm X 450mm
- Material of Chassis: 304 Stainless Steel
- Power Voltage: 208 - 240 VAC 1P
- Intermittent or Continuous Motion Available
- Dual Servo Motor Driven
- Variable PID Temperature Controls
- Vacuum Pull Belts
- Servo Motor or Pneumatic Driven Sealing Jaws Available
- Fill up to 130 BPM W/ Continuous Motion
- Motorized Tension Control On Film Unwinding
- Quick Changeover Film Roll and Former
What It's Used For
- Various dosing system available.
- Granule: volumetric cup filler, multi-head combination scale.
- Powder: auger screw filler.
- Liquid, paste: piston pump filler, magnetic pump filler, rotor pump filler.
- Vibration counting device
- Packed with heat sealable laminates film
High Tek USA
Rotary Pouch Bagger
Specifications
- Control System: Programmable Seimens PLC
- HMI: Seimens Smart Color Touch Screen
- Min Bag Size: 100mm (Width) X 210mm (Length)
- Max Bag Size: 300mm (Width) X 340mm (Length)
- Machine Size (LxWxH): 2503mm X 1977mm X 1610mm
- Max Speed: 45 Bags Per Minute
- Material of Chassis: 304 Stainless Steel
- Power Voltage: 208 - 240 VAC 3P or 480 VAC 3P
- 8 Positions: Bag Feed, Printer, Zipper Open, Bag Open,
- Fill/Vibrate/Nitrogen Flush, Exhaust & Seal, Cooling, Punch
